High Air Pressure SRC54 RC Reverse Circulation Hammer with 130mm Diameter and 84.5kg Weight for Efficient RC Drilling

Gambar besar : High Air Pressure SRC54 RC Reverse Circulation Hammer with 130mm Diameter and 84.5kg Weight for Efficient RC Drilling

Detail produk:

Tempat asal:	Hunan, Cina
Nama merek:	Sollroc

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1
Harga:	$1,500

Kontak

High Air Pressure SRC54 RC Reverse Circulation Hammer with 130mm Diameter and 84.5kg Weight for Efficient RC Drilling

Deskripsi

Berat:	84,5kg	Diameter:	130mm
Panjang:	1294 MM	Jenis Thread:	Remet / Metzke
Rentang lubang:	135-152mm	Betis sedikit:	SRC54/SRC54R
Tekanan kerja:	1.5-3.5Mpa	Tingkat dampak:	35HZ
Kecepatan rotasi:	25-40r/menit	Konsumsi Udara:	16m3/mnt pada 1.7mpa, 22m3/mnt pada 2.4mpa, 28m3/mnt pada 3.0mpa
Bahan:	Baja karburasi	Kedalaman maksimal:	500 meter
Utas koneksi:	4.5 '' Remet / 4.5 '' Metzke	Metode pengeboran:	Sirkulasi Kebalikan
pengambilan sampel:	Udara terkompresi
Menyoroti:	SRC54 RC Reverse Circulation Hammer , 130mm Diameter DTH Hammer , 84.5kg Weight Down The Hole Hammer

High Air Pressure SRC54 RC Reverse Circulation Hammer

The reverse circulation drilling method can reach depths of 500 metres. This pneumatic hammer device drills into the earth to extract rock samples, which are then transported to the surface via compressed air. Samples are collected in marked bags within the machine, allowing for multiple sample collection and precise tracking of extraction location and depth.

Key Features

Reduces overall drilling costs by up to 40% compared to conventional methods
Delivers faster results with rapid drilling process completion
Safe operation with reduced manpower requirements
Lower water consumption than alternative mining methods
Simple and efficient operation
Organized sample collection with detailed location and depth tracking for precise mineral deposit identification

Technical Specifications

Parameter	Value
Length (Without bit)	1294mm
Weight (Without bit)	84.5kg
External diameter	130mm
Bit Shank	SRC54/SRC54R
Hole range	135-150
Connection thread	4.5'' Remet 4.5''Metzke
Working Pressure	1.5-3.5Mpa
Impact rate at 2.4Mpa	35Hz
Recommended rotation speed	25-40r/min
Air consumption (1.7Mpa/2.4Mpa/3.0Mpa)	16m³/min / 22m³/min / 28m³/min

Quality Assurance

Our hammer and bits are manufactured from high-quality alloy steel with advanced heat treatment to ensure optimal drilling performance and extended service life. All products meet international standards and are trusted by customers worldwide.

Delivery & Packaging

Available shipping methods: Air freight, Sea freight, or Express delivery
Packaging options: Carton, Ply-wooden cases with Pallet

Product Images
